Intel Pentium Gold G5400 Dual Core 2 Cores 3.7GHz LGA 1151 / H4 / 4MB cache 58W 8th generation / Coffee Lake Desktop Processor BX80684G5400
Intel Pentium Gold G5400 Dual Core 2 Cores 3.7GHz LGA 1151 / H4 / 4MB cache 58W 8th generation / Coffee Lake Desktop Processor BX80684G5400
Detail Specifications
| Essentials Product Collection: Intel Pentium Gold Processor Series Code Name: Products formerly Coffee Lake Vertical Segment: Desktop Processor Number: G5400 |
| Performance Number of Cores: 2 Number of Threads: 4 Processor Base Frequency: 3.70 GHz Cache: 4 MB Bus Speed: 8 GT/s DMI3 TDP: 54 W |
| Supplemental Information Embedded Options Available: Yes |
| Memory Specifications Max Memory Size (dependent on memory type): 64 GB Memory Types: DDR4-2400 Max Number of Memory Channels: 2 Max Memory Bandwidth: 37.5 GB/s ECC Memory Supported: Yes |
| Processor Graphics Processor Graphics: Intel UHD Graphics 610 Graphics Base Frequency: 350 MHz Graphics Max Dynamic Frequency: 1.05 GHz Graphics Video Max Memory: 64 GB 4K Support: Yes, at 60Hz Max Resolution (HDMI 1.4): 4096x2304 at 24Hz Max Resolution (DP): 4096x2304 at 60Hz Max Resolution (eDP - Integrated Flat Panel): 4096x2304 at 60Hz DirectX Support: 12 OpenGL Support: 4.5 Intel Quick Sync Video: Yes Intel InTru 3D Technology: Yes Intel Clear Video HD Technology: Yes Intel Clear Video Technology: Yes Number of Displays Supported: 3 Device ID: 0x3E93 |
| Expansion Options Scalability: 1S Only PCI Express Revision: 3.0 PCI Express Configurations: Up to 1x16, 2x8, 1x8+2x4 Max Number of PCI Express Lanes: 16 |
| Package Specifications Sockets Supported: FCLGA1151 Max CPU Configuration: 1 Thermal Solution Specification: PCG 2015C (65W) TJUNCTION: 100oC Low Halogen Options Available: See MDDS |
| Advanced Technologies Intel Optane Memory Supported: No Intel Turbo Boost Technology: No Intel vPro Technology: No Intel Hyper-Threading Technology: No Intel Virtualization Technology (VT-x): Yes Intel Virtualization Technology for Directed I/O (VT-d): Yes Intel VT-x with Extended Page Tables (EPT):Yes Intel TSX-NI: No Intel 64: Yes Instruction Set: 64-bit Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2 Idle States: Yes Enhanced Intel SpeedStep Technology: Yes Thermal Monitoring Technologies: Yes Intel Stable Image Platform Program (SIPP): No |
| Security and Reliability Intel AES New Instructions: Yes Secure Key: Yes Intel Software Guard Extensions (Intel SGX): Yes Intel Memory Protection Extensions (Intel MPX): No Intel OS Guard: No Intel Trusted Execution Technology: No Execute Disable Bit: Yes Intel Boot Guard: Yes |
| Item Dimension ( L inch x W inch x H inch) 5 x 3 x 4 |
| Weight 1.00 lb |
| Warranty Information 3 years Limited Manufacture |
Intel Pentium Gold G5400 Dual Core 2 Cores 3.7GHz LGA 1151 / H4 / 4MB cache 58W 8th generation / Coffee Lake Desktop Processor BX80684G5400
- Part Number: 12563
- Brand: Intel
- Product Sku: BX80684G5400
-
Richmond BC Warehouse:Calgary AB Warehouse:Markham ON Warehouse:Back orderGuelph ON Warehouse:Back orderHalifax NS Warehouse:
- Availability: Call
-
$78.95
- Was: $118.43
